How to Change Battery in LiftMaster Garage Door Opener

Puzzled about how to change the battery in your LiftMaster garage door opener? You’ve landed on the right page!

Some LiftMaster garage door openers feature a battery backup to keep the opener working even when there is a power failure. As you already know, batteries aren’t designed to last indefinitely, so you need to replace them after a while.

First, get a new battery backup specially designed to work with your LiftMaster garage door opener. Next, remove the old battery and install the new one.

How do you do this?

Keep reading to discover the simple steps to replace the old battery in your LiftMaster garage door opener.

When to Replace Your Garage Door Opener Battery

If your LiftMaster garage door opener comes with a battery backup system, it is easy to know when the battery is too weak and needs to be replaced.

Usually, batteries in garage door openers should be replaced every one to two years. However, one of the telltale signs that you need to change the battery is a beeping sound.

Of course, most battery backup opener models from LiftMaster make a beeping sound if:

• The garage door opener is running on battery power.
• You’ve programmed the garage door to close using a timer feature.
• There’s an obstacle preventing the garage door from closing.

Still, you can easily tell when a beeping sound means it is time to replace the battery. Simply check the battery status LED on the garage door opener if you hear a beep. The battery status LED will turn a solid red, indicating that you need to change the battery.

You might not need a new battery if the battery status LED flashes orange. In that case, simply plug in the garage door opener to a main power source to charge the battery.

If you’re sure it is time to replace the battery, grab the tools listed below and follow the steps in this quick guide.

Tools You’ll Need

• Screwdriver for opening and closing the battery compartment
• Ladder (preferably a stepladder) for accessing overhead garage door opener
• Safety goggles and gloves for protection while working with the battery compartment

How to Change the Battery in a LiftMaster Garage Door Opener

If you’ve determined it is time to replace the battery in your garage door opener, the following simple steps will help you accomplish the task.

These steps work for all LiftMaster garage door openers, no matter the model. These instructions are tailor-made for overhead garage door openers, so it is usually best to consult your product’s instruction manual if your opener is different.

Step 1: Disconnect the Opener from the Power Mains

Although your old battery might be very weak or dead, it is still important to disconnect the garage door opener from the power mains before accessing the battery.

To do this:

• Grab a ladder and place it underneath the garage door opener.
• Climb the ladder and unplug the power cord of the garage door opener.

Step 2: Access the Battery

With the garage door opener disconnected, it is safe to access the old battery. You’ll need a screwdriver to do this. Here’s how:

• Open the light cover on the garage door opener to access the battery compartment.
• Grab your screwdriver and remove the screw on the battery compartment cover to access the old battery.
• Remove the battery from the compartment and gently pull the red and black wires from the battery terminals to disconnect them.

Step 3: Install the New Battery

Next, install the new battery in the garage door opener. Be sure to use the correct battery for your LiftMaster model. Consult the product’s manual if you’re unsure.

To install the new battery:

• Connect the wires from the battery compartment to the terminals on the battery, making sure to attach the red and black wires to their matching colored terminals.
• Insert the new battery into the compartment.
• Check to be sure that the battery wires are not pinched.
• Replace the battery compartment cover and screw it shut.
• Close the light cover of the garage door opener.

Step 4: Charge the New Battery

It is important to charge the newly installed battery. The charging time is usually 24 hours for a typical LiftMaster garage door opener.

To charge the battery:

• Plug the power cord of the garage door opener to the power mains.
• The battery status LED on the opener will blink green, indicating the battery is charging.
• The battery is fully charged when the battery status LED on the opener turns solid green.

Step 5: Test the Battery

Lastly, you should test the battery to make sure it is working as expected. This means you should cut off the power supply from the mains and operate the garage door opener using the wireless keypad or remote.

Here’s how to do this:

• Climb the ladder and unplug the garage door opener from the power mains. When the garage door opener is running on battery, the battery status LED will glow solid orange.
• Activate the garage door opener using the remote control if you have one. Alternatively, you can use the keypad.
• Your garage door should open and close as usual if the battery is fully charged. The garage door will run slowly, and the battery status LED will flash orange if the battery is low.
• After testing the battery, remember to plug in the garage door opener.

Changing the Battery in a LiftMaster Garage Door Opener

As you probably have figured out by now, the steps on how to change the battery in a LiftMaster garage door opener are straightforward, and you can do it, even if you don’t consider yourself to be handy.

If your new battery isn’t charging, check to make sure the wires are properly attached to the battery terminals. You may need to reattach the wires to ensure the power cord on the garage door opener is properly plugged into the power mains.
