LiftMaster LA500DC Residential/Light Commercial DC Linear Actuator
LiftMaster's most powerful swing gate operator delivers unsurpassed performance and secure access to your property. No other company can offer you that peace of mind.
Features
-
Keyed Manual Disconnect: Provides a simple method to manually operate the gate.
-
Fire Department Compliant: Selectable settings allow the gate to auto-open upon loss of AC power or battery depletion.
-
Bi-Part Delay: Monitors the speed and position of each wing and adjusts the speed as necessary to ensure primary gate closes last, avoiding potential damage to the gate.
-
Synchronized Close: Simultaneously closes gates.
-
Programmable Auxiliary Relays: Two programmable relays with six settings each simplify adding additional features. Switch on/off devices at open or close limits.
-
Advanced Traffic Management Control: Secures your property.
-
Anti-Tailgate: Prevents unauthorized access. Gate will pause when closing as vehicle pulls onto interrupt loop or breaks photo beam. Once the vehicle backs up, the gate will continue to close.
-
Quick Close: Closes the gate immediately after a vehicle pulls off the interrupt loop.
-
One-Touch Push Button Programmable Electronic Limit System: Maintains accurate gate position throughout gate travel. Maintains open and close limit position at all times, even after using manual disconnect.
-
Homelink® Compatible: Version 4 and higher.
-
Security+2.0™ On-Board Radio Receiver: Up to 50 remotes.
- Warranty: 2 years
Technical Specifications
-
Power: Full-time AC run operation 120V/230V Ø (Standard control box).
-
Accessory Power: 24VDC 500mA output Switched and unswitched power.
-
Surge: Industrial strength suppression on high and low voltage inputs.
-
Temperature Specifications: -40º F (-40C) to 140ºF (60C).
- Gate Travel Speed: 90 degrees opening in 15-17 seconds.
Capacity
LiftMaster LA500 Swing Gate Operator Unboxing Video
