USAutomatic Wireless Two Button Remote | USA-030210

USAutomaticSKU: USA-030210

Price:
Sale price$16.99

Estimate shipping

USAutomatic Wireless Two Button Remote | USA-030210

The Transmitter has been designed to control automatic opening
systems and anti-burglar systems. The operating frequency is 433.92 MHz.
During installation, the receiver must be connected to the device it controls (gate, rolling shutters, awnings, anti-burglar appliances, lighting). The transmitter security code is created by 9 ways three-position dipswitches. This allows up to 19,683 code combinations.

Features
  • Automatic Opening Systems
  • Anti-burglar systems
  • Up to 19,683 Transmitter Security Codes
  • 12/24 VDC Garage Door Receiver Available
Technical Specifications
  • Number of keys Supply: 2 / 4
  • Battery Type: 1 Alkaline Battery 12V type 23A
  • Battery life: 12 - 18 months
  • Current Consumption: 25 mA
  • Operating Frequency: 433.92 MHz
  • Code Combinations: 19683
  • Modulation: AM / ASK
  • Rated e.r.p.: 50 - 100 µW
  • Range in Free Space: 180 - 360 feet
  • Operating Temperature: 0 - 130 °F
  • Overall Dimensions: 3.26 x 1.88 x 0.62 in
  • Weight: 20 gr
