USAutomatic Wireless Two Button Remote | USA-030210
The Transmitter has been designed to control automatic opening
systems and anti-burglar systems. The operating frequency is 433.92 MHz.
During installation, the receiver must be connected to the device it controls (gate, rolling shutters, awnings, anti-burglar appliances, lighting). The transmitter security code is created by 9 ways three-position dipswitches. This allows up to 19,683 code combinations.
- Automatic Opening Systems
- Anti-burglar systems
- Up to 19,683 Transmitter Security Codes
- 12/24 VDC Garage Door Receiver Available
- Number of keys Supply: 2 / 4
- Battery Type: 1 Alkaline Battery 12V type 23A
- Battery life: 12 - 18 months
- Current Consumption: 25 mA
- Operating Frequency: 433.92 MHz
- Code Combinations: 19683
- Modulation: AM / ASK
- Rated e.r.p.: 50 - 100 µW
- Range in Free Space: 180 - 360 feet
- Operating Temperature: 0 - 130 °F
- Overall Dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 20 gr
