ASE HomeLink Compatible Mini Receiver | FAS-TS-NLRR318HL

All Security EquipmentSKU: FAS-TS-NLRR318HL

Price:
Sale price$39.00
Add to cart

ASE HomeLink Compatible Mini Receiver | FAS-TS-NLRR318HL

This receiver is designed to control automatic closing systems and anti-burglar systems, thanks to its very high-security coding system (KeeLoq Hopping code).

The receiver has 1 output relay with NO contacts and can be connected to many types of operators (gate, garage door, rolling shutters, awnings, anti-burglar appliances, etc.)

The programming can be done in a self-learning mode by means of one programming button.

Features
  • Mini size: 2" by 1-1/4" by 3/4"
  • 5-year warranty
  • 12-24 VAC/DC
  • Range: Up to 500' "Line Of Sight"
  • 1 channel
  • Can hold up to 44 transmitters (sold separately)
  • Compatible with a wide variety of handheld and wall-mounted transmitters
Technical Specifications
  • Receiver type: Superheterodyne
  • Local oscillator frequency: 6.6128 MHz
  • Demodulation: Am/ASK
  • Local oscillator: VCO / PLL
  • Channel width: > 25 KHz
  • Intermediate frequency: 10.7 MHz
  • Input sensitivity: -115 dBm
  • Local oscillator spurious emissions: < -57 dBm
  • Input load: 50 OhmMax applicable power: 24 VA
  • Relay number: 1
  • Contacts: C-NO
  • TX security code: 264
  • Operating temperature: -4° to 158° F
  • Housing protection: IP2X
Product Literature
