ASE LA400 Dual Premium
The ASE LA400 Dual Connected Classic is an all-in-one residential dual swing gate operator kit designed to make ordering easier and more convenient for professional installers. ASE combines the gate operators, access control devices, connectivity components, and commonly needed installation accessories into one complete package, reducing the time spent sourcing individual parts.
Built around the LiftMaster LA400PKGUL primary operator and LA400DCS secondary actuator, this kit provides a complete foundation for automating a dual residential swing gate. The included KPW5 wireless keypad and two 811LMX remotes provide convenient user access, while the FAS-HOOD helps protect the keypad and access equipment from outdoor exposure.
Includes
- 1 - LA400PKGUL
- 1 - LA400DCS
- 1 - KPW5
- 2 - 811LMX
- 1 - FAS-HOOD
- 1 - CP-4-100
- 1 - 828LM
Key Features
- All-in-One Dual Swing Gate Kit – Combines the LiftMaster LA400 primary operator, secondary actuator, wireless keypad, remotes, free-exit system, Internet Gateway, and protective hood in one convenient ASE package.
- Complete Dual Gate Automation – Includes the LA400PKGUL primary operator and LA400DCS secondary actuator for synchronized dual residential swing gate operation.
- Supports Gates Up to 16 ft. or 850 lbs. – Designed for residential swing gates within the LA400 platform’s rated capacity.
- 24VDC Continuous-Duty P3 Motor® – Provides dependable operation with an all-metal worm gear drive and a duty rating of up to 100 cycles per day.
- Battery Backup Included – Two 7Ah batteries help maintain gate operation during AC power interruptions.
- Security+ 2.0® Technology – Provides secure encrypted wireless communication with compatible LiftMaster access devices.
- KPW5 Wireless Keypad – Supports up to 5 permanent PINs and 10 temporary PINs, providing flexible access for residents, guests, and service personnel.
- NEMA 4X Outdoor-Rated Keypad – Features blue backlit metal keys and weather-resistant construction for dependable outdoor installation.
- 2 LiftMaster 811LMX Remotes – Includes two programmable single-button remotes for convenient vehicle access.
- Automatic Vehicle Free Exit – The included Cartell CP4-100 detects vehicles leaving the property and automatically activates the gate without requiring a keypad or remote.
- 100 ft. Vehicle Detection Cable – Provides installation flexibility with adjustable sensitivity and an IP67-rated enclosure.
- myQ Connectivity Included – The LiftMaster 828LM Internet Gateway enables compatible myQ features including smartphone control, remote status monitoring, alerts, and scheduling.
- ASE Protective Hood – Aircraft-grade aluminum construction with a powder-coated finish helps protect outdoor access equipment from water, dirt, dust, and debris.
- Solar-Ready Platform – The LA400 system can be configured for solar-powered applications with the appropriate compatible equipment.
- Installer-Friendly Premium Package – ASE combines gate automation, access control, vehicle detection, connectivity, and weather protection into one streamlined kit to simplify ordering and installation preparation.
