ASE HomeLink Compatible Mini Receiver | FAS-TS-NLRR318HL
This receiver is designed to control automatic closing systems and anti-burglar systems, thanks to its very high-security coding system (KeeLoq Hopping code).
The receiver has 1 output relay with NO contacts and can be connected to many types of operators (gate, garage door, rolling shutters, awnings, anti-burglar appliances, etc.)
The programming can be done in a self-learning mode by means of one programming button.
Features
- Mini size: 2" by 1-1/4" by 3/4"
- 5-year warranty
- 12-24 VAC/DC
- Range: Up to 500' "Line Of Sight"
- 1 channel
- Can hold up to 44 transmitters (sold separately)
- Compatible with a wide variety of handheld and wall-mounted transmitters
Technical Specifications
- Receiver type: Superheterodyne
- Local oscillator frequency: 6.6128 MHz
- Demodulation: Am/ASK
- Local oscillator: VCO / PLL
- Channel width: > 25 KHz
- Intermediate frequency: 10.7 MHz
- Input sensitivity: -115 dBm
- Local oscillator spurious emissions: < -57 dBm
- Input load: 50 OhmMax applicable power: 24 VA
- Relay number: 1
- Contacts: C-NO
- TX security code: 264
- Operating temperature: -4° to 158° F
- Housing protection: IP2X
Product Literature
Find answers to our most frequently asked questions below. Got more questions? Reach out to our friendly customer service team, they will be more than happy to assist you.
Estimate shipping
You may also like
Recently viewed
- Reviews
- Questions
Key to integrating with autos
I have a garage with 4 doors with commercial openers on them that do not have any receiver built in to them. I have them integrated with my home automation to open when someone arrives but there are times when we would just like to use the HomeLink in the car to open/close the door - enter this device. I bought 4 of them and connected them to the openers and programmed them to the cars and now we can have a backup switch to open or close the doors in the car.
All Security Equipment
Thank you so much for sharing your experience with the ASE HomeLink Compatible Mini Receiver! We're thrilled to hear that it seamlessly integrated with your commercial garage door openers and enhanced your home automation setup. Thanks again for choosing All Security Equipment!
Works but range is horrible.
All Security Equipment
Thank you for taking the time to share your feedback. If you haven't already, please reach out to our customer support team. We would like to gather more information about your specific setup and explore potential solutions to improve the range of your HomeLink Compatible Mini Receiver. Your satisfaction is our top priority, and we value your business.
