UNV 32 Channel 2 HDD NVR | UNV-NVR302-32E2

Introducing our cutting-edge Network Video Recorder (NVR) packed with advanced features and technical specifications to meet all your surveillance needs.

Features
  • Support Ultra265/H.265/H.264 video formats
  • 32-channel input
  • Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
  • HDMI and VGA simultaneous output
  • Up to 8 Megapixels resolution recording
  • Accurate retrieval, instant playback
  • 2 SATA HDDs, up to 6TB for each HDD
  • ANR technology to enhance the storage reliability when the network is disconnected
  • Support cloud upgrade
Technical Specifications

Video/Audio Input

  • IP Video Input: 32-ch
  • Two-way Audio Input: 1-ch, RCA

Network

  • Incoming bandwidth: 160Mbps
  • Outgoing bandwidth: 64Mbps
  • Remote Users: 128
  • Protocols: P2P, UPnP, NTP, DHCP, PPPoE

Video/Audio Output

  • HDMI/VGA Output
    • HDMI:4K (3840x2160) @30, 1920x1080p@60, 1920x1080p@50, 1600x1200@60, 1280x1024@60, 1280x720@60, 1024x768@60
    • VGA:1920x1080p@60, 1920x1080p@50, 1280x1024@60, 1280x720@60, 1024x768@60
  • Audio Output: 1-ch, RCA
  • Recording Resolution: 8MP/5MP/4MP/3MP/1080p/960p/720p/960H/D1/2CIF/CIF
  • Synchronous Playback: 32-ch
  • Corridor Mode Screen: 3/4/5/7/9/10/12/16/32

Decoding

  • Decoding format: Ultra265/H.265/H.264
  • Live view/Playback: 8MP/5MP/4MP/3MP/1080p/960p/960H/720p/D1/2CIF/CIF
  • Capability: 2 x 4K@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30, 8 x 1080p@30, 16 x 720p@30,32 x D1

Hard Disk

  • SATA: 2 SATA interfaces
  • Capacity: up to 6TB for each disk

External Interface

  • Network Interface: 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces
  • USB Interface: Rear panel: 1 x USB2.0, 1 x USB3.0 Front panel: 1 x USB2.0

General

  • Power Supply: 12V DC
  • Power Consumption: ≤ 15W( without HDD )
  • Working Environment: -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)
  • Dimensions (W×D×H): 380mm × 315mm ×53mm (15.0" × 12.4" ×2.1" )
  • Weight (without HDD): ≤ 2.48 Kg (5.47lb)
