Magnetic Autocontrol Traffic Barrier 20' Passage | MAG-TRAFFIC H1LE-SC02000

Magnetic AccessSKU: MAG-TRAFFIC H1LE-SC02000

Sale price$5,443.71
Add to cart


Magnetic Autocontrol Traffic Barrier 20 ft. Passage | MAG-TRAFFIC H1LE-SC02000

Traffic Barrier 20 ft. Passage. Must use a cable support.


Please allow an extended lead time due to manufacturing and shipping for this product. For questions or additional information, please contact customer support at (800) 730-8382.

  • High functionality for numerous special applications
  • Patented folding barrier arm for safety at indoor crossings with differing lane widths
  • Low power consumption for economical operation
  • Optimum accessibility for particularly simple maintenance
  • Form-based on the prizewinning design of the Access barriers
Technical Specifications
  • Barrier width: Max. 20 ft
  • Opening/closing time: 4.0 s
  • Power consumption: Max. 45 W
  • Drive technology: MHTM™
  • Voltage: 85–264 VAC, 50/60 Hz
  • Housing dimensions (W xD x H) with support: 12.2 x 14.2 x 53.4 in
  • Housing dimensions (W x D x H) without support: 12.2 x 14.2 x 37 in
  • Enclosure rating: IP 54
  • Temperature range: −22 to +131 °F
  • Weight (without barrier arm): 121.3 lb
Manufacturer's Warranty Period
  • 2 years or 2 million cycles (whichever occurs first)
