EMX Microwave Sensor | EMX-HAWK2

The HAWK 2 vehicle motion sensor utilizes K-band microwave technology to detect people and vehicles from an overhead position. It provides wide coverage and high resolution to activate all types of automatic doors and industrial gates. The HAWK 2 is easily installed at a height up to 20 feet (6 meters). With its versatile mechanical orientation, the HAWK 2 ensures accurate positioning to the required coverage area. The detection sensitivity and direction of movement (approaching, leaving or both) are programmed by DIP switch settings.

Features
  • K-band microwave technology
  • Easy installation and adjustment
  • Directional sensitivity
  • Programmable functions
  • Wide coverage area
Manufacturer's Warranty
  • 2 Years
Technical Specification
  • Operating Frequency: 24.150 GHz
  • Output Power (EIRP): <20dBm
  • Detectable Speed: 0.1 m/s min.
  • Vertical Directionality: 0-60°
  • Horizontal Directionality: +/- 45°
  • Installation Height: 10-20ft (3-6m)
  • Range: 1-10m adjustable
  • Relay Control Time: 1-6 sec. adjustable
  • Relay Output Configuration: Form C (SPDT)
  • Relay Contact Rating: 1A @ 24 VDC/AC
  • Detection Indicator: Red LED
  • Operating Temperature: -4°F -122°F (-20°C-50°C)
  • Supply Voltage: 12-24 VDC/AC
  • Operating Current: 40mA (relay activated)
  • Dimensions: 6.3”(160mm) x 3.8”(95mm) x 4.4”(110mm)
  • Weight: 1.0 lbs. (450g)
  • Housing: ABS (plastic)
  • Connection: 6.5ft (2m) cable
  • Mechanical Protection: IP65
