Bolide ETL Solid Copper Core Siamese Cable 500' in White | BTG-BP0033C

Bolide Technology GroupSKU: BTG-BP0033C

Price:
Sale price$116.00
Add to cart

Description

Bolide ETL Solid Copper Core Siamese Cable 500ft in White | BTG-BP0033C

500FT ETL Solid Copper Core 95% Coverage RG59+18/2 Siamese Cable in White.

Features
  • RG59 combo coax cable with 18 gauge 2 conductor heavily shielded cable is Ideal for Composite Video, RGBHV Video, Component Video and even Surveillance Systems
  • Attached 2 Stranded copper 18AWG 7x0.385mm Black/Red Power Cable
  • UL Listed 20AWG Center Conductor
  • ISO 9000 Certified* 95% Coverage Braid Shield in Spool Box
  • The advantages to using RG59 cable is that its more durable and can be run in long distances without interference. You can also cut each security camera run the exact length that you need.
Technical Specifications
  • Color: White
  • Length: 500 FT
  • Dialectric: Gas Injected Foam POE
  • Conductor: CCAM (Copper Clad Aluminum Magnesium)
  • Shielding: 95% Braid Coverage
  • Jacket: 75° PVC U/V BLACK
  • Nom. Imp (Ω ): 75
  • Nom. Vel of Prop.: 82%
  • Attenuation (100ft): Freq. 1 MHz, 033 dB Freq. 10 MHz, 0,88 dB Freq. 50 MHz, 1,85 dB Freq. 100 MHz, 2,51 dB Freq. 200 MHz, 3,58 dB Freq. 4000 MHz, 5,29 dB Freq. 700 MHz, 7,45 dB Freq. 900 MHz, 8,7 dB Freq. 1000 MHz, 9,31 dB
  • Product Dimensions: 13.2 x 12.8 x 12.8 inches
  • Item Weight: 37.8 pounds
Product Literature
